| September 2011: Kinetics Industries ships 3300 Kilowatt, 275 VDC 12,000 Amp, double ended, SCR regulated rectifier substation to a western Canadian steel mill for melt shop ladle crane operation. 3300 Kilowatt, 275 VDC, 12,000 Amps, Double Ended, SCR Regulated Rectifier Substation
Designed & manufactured By Kinetics Industries: Delivered August 2011
Two 1650 Kw Rectifiers Suitable for Independent or Parallel Balanced Load Sharing
Application: Canadian Steel Mill – Melt Shop Ladle Crane Power
Transformer & IPT / SCR Rectifier / Drawout 2 Pole Breakers / SCR Rectifier / IPT & Transformer
6900/3/60-2180 KVA---1650 kilowatts--2 Mains 1 Tie & 3 Feeders--1650 kilowatts---2180 KVA-6900/3/60
Two 165 Kw Regenerative Absorption Circuits - One Per Rectifier
System Description & General Parameters:
• Two AC inputs 6900/3/60
• Two SCR regulated rectifiers, +/1%
• Each rectifier rated 6,000 ADC @ 275 VDC
• Load sharing 12,000 ADC master/slave
• HMI annunciation & digital outputs
• CSA marked product |
• 7 DC drawout, cradle mounted, circuit breakers
• Transformers & Inter-phase transformer designed & manufactured by Kinetics
• SCR firing circuit & power assemblies designed and manufactured by Kinetics
• Enclosures designed & manufactured by Kinetics |
|
